CPU Specifications

Total Cores 12

# of Performance-cores8

# of Efficient-cores4

Total Threads 20

Max Turbo Frequency 5.00 GHz

Intel® Turbo Boost Max Technology 3.0 Frequency ‡ 5.00 GHz

Performance-core Max Turbo Frequency 4.90 GHz

Efficient-core Max Turbo Frequency 3.80 GHz

Performance-core Base Frequency3.60 GHz

Efficient-core Base Frequency2.70 GHz

Cache 25 MB Intel® Smart Cache

Total L2 Cache12 MB

Processor Base Power 125 W

Maximum Turbo Power 190 W

Supplemental Information

Marketing StatusLaunched

Launch Date Q4"21

Embedded Options Available No

DatasheetView now

Memory Specifications

Max Memory Size (dependent on memory type) 128 GB

Memory Types Up to DDR5 4800 MT/s

Up to DDR4 3200 MT/s

Max # of Memory Channels 2

Max Memory Bandwidth 76.8 GB/s

Expansion Options

Direct Media Interface (DMI) Revision4.0

Max # of DMI Lanes8

Scalability1S Only

PCI Express Revision 5.0 and 4.0

PCI Express Configurations ‡ Up to 1x16+4, 2x8+4

Max # of PCI Express Lanes 20

Package Specifications

Sockets Supported FCLGA1700

Max CPU Configuration1

Thermal Solution Specification PCG 2020A

TJUNCTION 100°C

Package Size45.0 mm x 37.5 mm

Advanced Technologies

Intel® Gaussian & Neural Accelerator 3.0

Intel® Thread DirectorYes

Intel® Deep Learning Boost (Intel® DL Boost) Yes

Intel® Optane™ Memory Supported ‡ Yes

Intel® Speed Shift Technology Yes

Intel® Turbo Boost Max Technology 3.0 ‡ Yes

Intel® Turbo Boost Technology ‡ 2.0

Intel® Hyper-Threading Technology ‡ Yes

Intel® 64 ‡ Yes

Instruction Set 64-bit

Instruction Set Extensions Intel® SSE4.1, Intel® SSE4.2, Intel® AVX2

Idle States Yes

Enhanced Intel SpeedStep® Technology Yes

Thermal Monitoring Technologies Yes

Intel® Volume Management Device (VMD) Yes

Security & Reliability

Intel® Standard Manageability (ISM) ‡ Yes

Intel® Control-Flow Enforcement Technology Yes

Intel® AES New Instructions Yes

Secure Key Yes

Intel® OS GuardYes

Execute Disable Bit ‡ Yes

Intel® Boot Guard Yes

Mode-based Execute Control (MBEC) Yes

Intel® Virtualization Technology (VT-x) ‡ Yes

Intel® Virtualization Technology for Directed I/O (VT-d) ‡ Yes

Intel® VT-x with Extended Page Tables (EPT) ‡ Yes
